SUPER-RAIL ECO DOUBLE H2-W4
- Description
- Technical data
- Product view
Description
Super-Rail Eco Double is a H2 level road restraint system for median side.
The Super-Rail Eco Double consists of a top beam to prevent heavy vehicles from tipping over and a bottom beam dedicated to light vehicles.
Technical data
SPECIFICATIONS:
Tested length: 52m in H2 level.
CE mark N° : 0049 - CPR - 2010
Available connections: Super-rail Eco (H2-W4-B) and HBB 1.33 Plus (L1-W3-A)
Post: C125 en acier S235 JR;
Length: 1,90 m
Beam profile: AD profile in S235 JR steel
Weight per lm: 52,5 kg
Post spacing: 2.0 m
